ENGAGE™ 8440
ENGAGE ™ 8440 Polyolefin Elastomer is an ethylene-octene copolymer that performs well in a wide range of thermoplastic elastomer applications.It is an excellent thermoplastic elastomer for blending and compounding.
Introduction
ENGAGE ™ 8440 Polyolefin Elastomer is an ethylene-octene copolymer that performs well in a wide range ofthermoplastic elastomer applications.It is an excellent thermoplastic elastomer for blending and compounding.
Parameters
| Nominal Value (English) | Nominal Value (SI) | Test Method | ||
| Physical | Density | 0.897 g/cm3 | 0.897 g/cm3 | ASTM D792 |
| Melt Index (190℃/2.16 kg ) | 1.6 g/10min | 1.6 g/10min | ASTM D1238 | |
| Mooney Viscosity (ML 1+4, 250°F(121℃)) | 13 MU | 13 MU | ASTM D1646 | |
| Mechanical | Tensile Modulus-100% Secant1 (Compression Molded) |
914 psi | 6.30 MPa | ASTM D638 |
| Tensile Strength1 (Break, Compression Molded) |
2960 psi | 20.4 MPa | ASTM D638 | |
| Tensile Elongation 1
(Break, Compression Molded) |
690 % | 690 % | ASTM D638 | |
| Flexural Modulus
1% Secant : Compression Molded 2% Secant : Compression Molded |
7860 psi
7880 psi |
54.2 MPa
54.3 MPa |
ASTM D790 | |
| Elastomers | Tear Strength 2 | 451 lbf/in | 78.9 kN/m | ASTM D624 |
| Hardness | Durometer Hardness
Shore A, 1 sec, Compression Molded Shore D, 1 sec, Compression Molded |
86
36 |
86
36 |
ASTM D2240 |
| Thermal | Glass Transition Temperature | -27.4 °F | -33.0 ℃ | Dow Method |
| Vicat Softening Temperature | 167 °F | 75.0 ℃ | ASTM D1525 | |
| Melting Temperature (DSC) 3 | 199 °F | 93.0 ℃ | Dow Method | |
| Peak Crystallization Temperature (DSC) | 169 °F | 76.0 ℃ | Dow Method |
Notes
These are typical properties only and are not to be construed as specifications. Users should confirm resuits by their own tests.
1 20 in/min (510 mm/min)
2 Die C
3 10°C/min
Application
- Thermoplastic elastomers
- Compounding
Features
- Pellet form
Parameters
| Minimum Order Quantity: | 25kg |
| Price: | $1.5-$3 |
| Packaging Details: | 25kg/bag |
| Delivery Time: | 3-5 working days to departure port |
| Payment Terms: | TT/LC |
| Supply Ability: | 1000MT/Month |
